Ntn Ucp211-203D1 Pillow Block Bearing, Cast Iron Housing Material, Set Screw,
USD 131.99 USD
Specifications
| Brand | NTN |
| Width | 2.900 |
| Bore Diameter | 2-3/16" |
| MPN | UCP211-203D1 |
| Model | UCP211-203D1 |
| Style | Pillow Block Bearing |
| Item | Pillow Block Bearing |
| Overall Length | 8-5/8" |
| Type | Pillow Block Bearing |
| Overall Height | 4-31/32" |
| Overall Width | 2-3/8" |
| Weight | 7.7300 |
| Bearing Type | Ball |
| Height | 4-31/32" |
| Length | 5.300 |
| Depth | 2.900 |
| Series | Standard Duty |
| Housing Material | Cast Iron |
| Dimension E | 2-25/64" |
| Bearing Material | Steel |
| Static Load Capacity (Lb.) | 6570 |
| Dynamic Load Capacity (Lb.) | 9750 |
| Bore Dia. | 2-3/16" |
| Dynamic Load Capacity | 9750 lb. |
| Static Load Capacity | 6570 lb. |
| Bolt Size | 5/8" |
| Locking Type | Set Screw |
| Bolt Hole Size | 5/8" |
| UPC | 4547359503371 |
The NTN brand gives this ball bearing a confident feel right out of the box.
